- 1. Supporting Android phone(Samsung Galaxy S) environment (Supporting additional I/O)
2. Powerful processor for smart phone, S5PC110(Cortex A8 1GHz)
3. Various devices for communication
(USB 2.0, RS232, IrDA, Zigbee 2.4GHz, Bluetooth V3.0, WiFi 802.11 b/g/n, Ethernet)
4. 7“ WVGA(800 × 480) Touch LCD
5. Full HD Video HDMI OUT 6. Supporting DMB, GPS, Camera
| General Specifications and display | |
| PROCESSOR | Samsuag S5PC110(Cortex A8 1Ghz) |
| DISPLAY | 7" TFT LCD, 480x 800 pixels |
| System software | Kernel 2.6.29, Android Éclair 2.1 |
| Air Interface | WiFi- 802.11 b/g |
| Display color depth | 24bit/pixel |
| Multi-touch panel | Capacitive |
| Primary keypad | Capacitive Touch Standard 3 key : Back, Home, Menu |
| Connectivity | |
| BlueTooth | 2.0 +EDR |
| USB | Standard USB 2.0 Hosted, Supports 3G and GPS Module |
| MICRO USB | Device mode includes charging |
| Digital TV OUT | Standard HDMI Port |
| Analog TV OUT | 3.5mm Jack (Video RCA / Audio RCA) |
| Sensor | 3-axis accelerometer for UI auto-rotate |
| Power | |
| Power adapter | 5V / 1A |
| Memory | |
| T-Flash | 2GB |
| SD Card | 4 GB supprot up to 32 GB |
| Built-in Flash | NAND 512 MB |
| Memory | |
| Built-in Mucro SD T-Flash | 2GB |
| SD Card | 4 GB supprot up to 32 GB |
| Built-in Flash | NAND 512 MB |
| Entertainment | |
| Media player | MP3/WAV/AAC/AC3/MP4/H.264/MIDI |
| Streaming media | Supports H.264+AAC based MP4 container format |
